Hands-On Live Practice

• Android Sandwich Board
• Single & Double Decker CPU
• Advanced CPU Replacement Techniques
• Latest Software & Bypass Methods
• 5G Motherboard Expert Analysis
• Dual Battery & Hyper Charging Systems

Safe Component Identification & Removal

M/PMI, Glass IC, BGA, WCN, EMMC, EMCP, BQ, FCP, SMP, Shield, Sensor, etc.

Circuit Activity Training

Buck & Boost Converter LDO, Voltage Divider, VDC, etc.

Voltage Measurement & GR Testing

Using DC Machine, Fluke/Sunshine Digital Multimeter and Rigol - DSO

Cool/Hot Testing Parameters

VPH, VBUS, VREG, BOB, BUCK, BOOST, LDO, etc.

Android Fault Diagnosis Techniques

• Motherboard Fault Finding (Including 5G Models)
• Dead Phone Recovery:
• Hardware: Short circuits, leakage, dead CPU, (Including Thermal Camera & Short Killer)etc
• Software: Dead due to software, health issues, upgrade/downgrade logic
• Why & When to Replace CPU/EMMC

Oscilloscope Protocol Operations

• I2C, I3C, I2S, SPI, DSI, CSI, PDM, RFFE, MIPI
• Pull-Up/Down Process

Schematic & Diagram Analysis

• Tools: Borneo, Pragmafix, Orion (Estech) etc
• Diagram Browsing
• Boot Sequences: MTK, Qualcomm, Exynos, SPD, SoC
• 4G/5G Circuit Flow - Deep Explanation

Special Hand Skill Tips & Tricks

• White/Black Paste Dual Decker
• Single SoC Black/White Paste
• Expert Reballing Skills

Advanced Software Training

• Flash 64, eazy -Jtag, MIPI tester Gear2, AMT, Schimera tool, UFI, UMT, MFT, Unlock Tools... Etc.
• CPU Drilling, ISP Pinout
• EMMC/UFS Programming

Storage Deep-Dive

• Bad Health Solutions
• MBR/GPT Explained
• RPMB (Read/Write)
• Boot Config & LUN
• Dump Creation
• OTP Explained

Additional Modules

• Network, Graphics, Display, Audio, Backlight Repair
• Samsung CPU & RAM Handling
• RAM Changing Practice on Working Boards

Precision Techniques

• UV Curving & Under Masking
• Jumpering & Micro Jumpering
• Fault Finding – From Basics to Advanced
• Dead Phone Data Recovery
